Palletizer
VPM-BL
VPM-BL – Compact and Flexible Palletizer for Boxes and Crates
The VPM-BL is a compact palletizing machine for boxes and crates based on the sliding principle. Thanks to its versatile design, the machine is able to process various product sizes and stacks quickly and consistently. The VPM-BL is equipped innovative technology as standard and can be fitted with an optional automatic pallet support system, transforming semi-automatic operations into fully automated solutions – perfect for maximizing efficiency while saving space.
Products are fed in by the stable conveyors with automatic product buffering. Once the VPM-ACP’s turn unit and sliding arm positions products right where they need to be, the horizontal formation doors place every layer precisely on the pallet. The four-sided, closed collar ensures each stack has a flawless finish. The machine includes a user-friendly touchscreen and intelligent software. With remote access technology, our service team can provide immediate support from anywhere.
Specifications
| Model features | |
|
Touch screen with user-friendly interface |
|
|
Easy configurable stacking patterns |
|
|
Remote access module |
|
|
High infeed level |
|
|
Low infeed level |
|
|
Automatic stack / support transport |
|
|
Vertical compression |
|
|
Entrance protection |
|
|
Access platform |
|
| Specifications | |
|
Capacity (max. rate depending on configuration) |
|
|
5 units per layer |
780 units/hour |
|
10 units per layer |
1575 units/hour |
|
Max. layer dimensions (mm) |
1250×1250 |
|
Package |
|
|
Maximum weight (kg) |
25 |
|
Minimum dimensions (mm) |
200 x 200 x 100 |
|
Maximum dimensions (mm) |
400 x 600 x 400 |
Benefits
- Consistent and stable pallet stacks
- Fast stacking capability
- Low power consumption
- Efficient and low maintenance
- High return and short ROI
Popular options and add-ons
- Adjustable formation collar for multiple pallet dimensions
- Integrated sheet and interlayer dispenser
- Advanced sliding arm boosts capacity
- Empty pallet dispenser
- Slip sheet / nail guard dispenser for push-pull attachments
- Driven roller conveyors
- Fully integrated automatic wrapping machine
